Įquations 7 and 8 will help choose the magnitudes of the feedback resistors:įor the inverting circuit, Equation 9 determines R2 as: Solve for R1 and R2 so that f p_cin is between 2 and 10 times larger than BW CL. For a noninverting circuit, use Equation 2 as the constraint for the ratio of R1 and R2 and then rearrange Equation 5. Therefore, it is best to make f p_cin between 2 and 10 times larger than BW CL. If f p_cin is only slightly more than BW CL, it will still impact the loop gain phase margin. As long as BW CL is a lower frequency than the pole frequency determined by the right-hand side of the equation, there will be minimal impact on system stability from the input capacitance.Ī pole or zero starts to impact the phase of a system one decade before the corner frequency. The left-hand side of Equation 6 defines the closed-loop bandwidth, BW CL. Where G cl is the noninverting closed-loop gain of the system as shown in Equation 2 and GBW is the gain bandwidth of the op amp. While you don’t usually use extreme resistor values (tens of ohms or gigaohms) because of op-amp input bias current and output current limits, kiloohm-value resistors may cause issues by interacting with an op amp’s input capacitance.Įquation 6 makes it easy to check if there is a potential issue: One is to consider the input capacitance when choosing the magnitude of resistors for the circuit’s feedback network. Now that you understand the impact of input capacitance, there are a few ways to address the problem. Using Equation 5, the higher gain circuit will have a pole frequency nearly five times greater than the lower gain circuit.įinishing the design and making it stable For example, compare the equivalent resistance at two different gains: Looking at Equations 1 and 2, it’s possible to obtain higher gains with smaller values of R1. One additional advantage of a higher gain configuration is a typically lower equivalent resistance for the feedback network. It can be see in Figure (a) and (b).Figure 9 ROC with increased closed-loop gain That is why input terminal 2 is called inverting terminal. When positive Vin2 acts alone, the output voltage is inverted and terminal 3 becomes positive with respect to terminal 4. When positive Vin1 acts alone, it produce a differential output voltage with terminal 4 positive with respect to terminal 3 that is why the input terminal 1 is called non-inverting input terminal. in other words the output between collectors would be zero. If two in-phase and equal signals are applied at the two input terminals, the resultant output signal at each output terminal would be zero this is shown in Figure (d). The resultant output signals have a peak value twice the value for single ended operation. Input signal at each input terminal causes signal to appear at both output terminals. This type of operation is also referred to as double ended operation. In this mode two opposite polarity (out of phase) signals are applied to the inputs as shown in Figure (c).
When input signal Vin2 is applied to input terminal 2, an amplified and inverted signal appears at output terminal 4 whereas equally amplified but in phase signal appears at terminal 3 this is shown in Figure (b). In Figure (a) input signal is applied to terminal 1 and terminal 2 is ground.įigure shows that an amplified and inverted output signal is obtained at V01 but an equally amplified and in phase signal appears at V02 which is terminal 4. When a differential amplifier is operated in this mode, one input is ground and the signal voltage is applied only to the other input. The operational amplifier works in different modes depending on the nature of its job. In analog computers it is often referred to as the basic linear (or analog) integrated circuit (IC). The operational amplifier or OP-AMP is a direct coupled, high gain amplifier used to perform a wide variety of mathematical operation used to perform like summation, subtraction, multiplication, differentiation and integration etc.
